USB Movie Playback
Play Videos straight from a USB storage device
Bass Blast
Experience powerful bass through a specially tuned sound matrix. Bass Blast realizes dynamic and deep bass sound quality.
SPECIFICATIONS
PHYSICAL – SIZE (W × H × D)mm
-
- Main
- 360 × 60.5 × 299
- Front Speaker
- 250×1100×250
-
- Center Speaker
- 260×93×74
- Rear Speaker
- 250×1100×250
-
- Subwoofer
- 191×388.5×318
AMPLIFIER
-
- CH
- 5.1
- POWER OUTPUT – Total
- 1000W
-
- Power Output – Front L/R
- 167WX2
- Power Output – Center
- 167W
-
- Power Output – Surround L/R
- 167W×2
- Power Output – Sub-Woofer
- 167W(Passive)
DESIGN(MAINSET)
-
- Front & Rear cabinet (tray)
- Yes
HOME MENU
-
- Home Menu
- Yes
IN & OUT FRONT
-
- Display
- FLD
- USB
- 1
-
- Audio In – Portable In
- Yes
IN & OUT R/PANEL
-
- Video Out – Composite
- Yes
- Audio Input – Audio L/R
- Yes
-
- Audio Input – Optical
- 1
- Audio Input – Out
- 1
-
- Radio Antenna – FM
- Yes
- Speaker Terminal – Composing of channel
- 5.1
-
- Speaker Terminal – Terminal Type
- Push in (Spring)
CONVENIENCE
-
- SIMPLINK
- Yes
- Speaker Level Trim
- Yes
-
- Speaker Distance (channel delay)
- Yes
- Test Tone
- Yes
-
- Mute
- Yes
- A/V Sync Delay(Audio Delay)
- Yes
-
- Dimmer
- Yes
- Sleep
- Yes
-
- Volume on TV
- Yes
- USB Direct Recording
- Yes
-
- TV Sound (direct key)
- Yes
- TV Sound Sync (Bluetooth)
- Yes
-
- Dynamic Range Control On/Off
- Yes
- Bluetooth (Rx )
- Yes
DISC & AV FORMAT
-
- DVD(NTSC)
- Yes
- DVD(PAL)
- Yes
-
- DVD-R
- Yes
- DVD-RW(Video)
- Yes
-
- DVD+R
- Yes
- DVD+RW(Video mode)
- Yes
-
- CD-R/CD-RW
- Yes
- MPEG2
- Yes
-
- XvId
- Yes
- LPCM
- LPCM
-
- Dolby Digital
- Yes
- MPEG 1/2 L2
- Yes
-
- MP3/ID3 Tag
- Yes/Yes
- WMA
- Yes
-
- Graphics/Subtitle Format
- 2bit/ 8bit Sub-picture / Text-based Subtitle
- Video DAC
- 148MHZ/12bit
-
- NTSC/PAL Hz
- 60Hz / 50Hz
- Resolution
- upto 1080p24/60Hz
-
- VBI – WSS/CGMS-A/Closed Caption/Macrovsion
- Yes
- NTSC⇔PAL Conversion
- Yes
-
- Last Scene memory
- Yes
DISC(BD, DVD, CD)PLAYBACK SPECIFICATION
-
- Screen Saver
- Yes
- Auto Power Off
- Yes
-
- Parental Lock
- Yes
- Initial logo
- Yes
-
- DVD – 1080p Upscaling
- Yes
- Trick Play – Fast Forward
- Yes
-
- Trick Play – Fast Back
- Yes
- Trick Play – Forword Slow
- Yes
-
- Trick Play – Pause
- Yes
- Trick Play – Forward Step
- Yes
-
- Search – Title/Track
- Yes
- Search – Chapter
- Yes
-
- Search – Time
- Yes
- Repeat Play – Title/Track
- Yes
-
- Repeat Play – Chapter
- Yes
- Resume Stop
- Yes
-
- Play Mode – Random
- Yes
- Marker Play
- Yes
POWER
-
- SMPS
- 110-240, 50/60Hz
- Power Off Consumption
- 0.5W ↓
-
- Power Consumption
- 135W
RADIO
-
- Tuner Type
- PLL
- Tuning Up/Down
- Yes
-
- Preset Up/Down
- Yes
- Band(FM)
- Yes
-
- Preset Memory
- 50 Station
SPEAKER
-
- Front – Model Name
- S65T1-S
- Front – SPL
- 81
-
- Front – System
- Closed type
- Front – Woofer Unit
- 3″ Paper
-
- Front – Impedance
- 3Ω
- Front – Magnetic Shielding
- Non-Shielded
-
- Rear – Model Name
- S65T1-S
- Rear – SPL
- 81
-
- Rear – System
- Closed Type
- Rear – Woofer Unit
- 3″ Paper
-
- Rear – Impedance
- 3Ω
- Rear – Magnetic Shielding
- Non-Shielded
-
- Center – Model Name
- S63T1-C
- Center – SPL
- 79
-
- Center – System
- Closed type
- Center – Woofer Unit
- 3″ Paper
-
- Center – Impedance
- 3Ω
- Center – Magnetic Shielding
- Non-Shielded
-
- Subwoofer – Model Name
- S75T1-W
- Subwoofer – SPL
- 83
-
- Subwoofer – System
- Bass Reflex
- Subwoofer – Woofer Unit
- 7″ Paper
-
- Subwoofer – Impedance
- 3Ω
- Subwooder – Magnetic Shielding
- Non-Shield
FEATURE LIST – ACCESSORY KIT
-
- Instruction Manual
- Printing Book
- Remote Control Unit – Type
- CB1
-
- Remote Control Unit – Unified
- Yes
- Remote Control Unit – Battery(Size)
- AAA*1
-
- Batteries (Remote Controller)
- Yes
- FM Antenna
- Yes
-
- Speaker Cable
- Yes (5 EA)
- Warranty Card
- Yes
-
- RCA Code(Video), Yellow, 1P
- Yes
- HDMI Cable
- Yes
-
- Optical Cable
- Yes
- Carton Box Type (Tip on, Offset, Flexo)
- Tip on
